Fire Sprinkler Design & Consultancy

Fire Sprinkler Design Service

Sprinkler Design & Consultancy Service

The design of a sprinkler system is vital to its efficient operation and effectiveness. Each fire sprinkler head needs to be positioned such that it will provide the best possible protection for the space. In addition, the aesthetic appearance needs to be considered. Further more the pipe routes and diameters need to be carefully planed and calculated to ensure compliance to the required standards, maximise performance and control costs.

We offer a full design service with all our installation work

Our fire sprinkler design service is a compilation of: skillfully designed CAD drawings produced by specialised designers, hydraulic calculations which determine the water flow and pressure of the system to ensure the system can meet the hydraulic demand required, as well as noting the correct pipe sizes and heads to be used. This package provides a clear understanding of the systems requirements so that we can achieve the most cost-effective design whilst ensuring it complies with accordance to the most recent British Standard.

Benefits of our sprinklers design service include:

  • Our design work is undertaken in house by experienced residential sprinkler designers.
  • Full CAD drawings with calculations to demonstrate compliance to British Standards.
  • Drawings are presented to the client and discussed prior to approval.
  • Our design service is offered alongside our consultancy service.
  • We can offer the same service to any competent person or company looking to install a sprinkler system.

Fire Sprinkler Consultancy

Sprinklers Direct offer a comprehensive consultancy service for companies or individuals looking to install residential sprinkler systems or for building design specifications, including:

  • Initial assessment (system selection, risk category)
  • Site surveys
  • Water supply testing
  • Design parameters
  • Installations (Practical)
  • BS9251 interpretation BS9251

Purchase the latest British Standards here

Design Service

Please use the form below to make an enquiry and upload drawings and technical details direct to our design team.

Fire Sprinklers Design Form

Maximum file size: 67.11MB


Back to Fire Sprinklers


Fire Sprinkler Service & Maintenance

Fire Sprinkler Service & Maintenance

Fire Sprinkler Service, Safety Checks and Maintenance Domestic and residential fire sprinkler systems should be checked annually. The checks ensure...
Watermist Systems

Watermist Systems

Sprinklers Direct install Fire Sprinkler Systems to Domestic & Residential properties. Watermist systems are an alternative source of fire prevention...
Fire Sprinkler Design & Consultancy

Fire Sprinkler Design & Consultancy

Sprinkler Design & Consultancy Service The design of a sprinkler system is vital to its efficient operation and effectiveness. Each...
Dry Risers Direct Ltd

Dry Risers Direct Ltd

Dry Risers Direct Ltd Our sister company offers a great value ‘no fuss’ service which is smoothly delivered with minimum...

Fire Sprinkler Design & Consultancy Case Study

The Cosmopolitan, Commercial Road, Poole

Client: Harbourview Construction

Risk Category: Cat 2 – Partial cover
Number of heads: 151
System Type: Shared Cold-Water Tank & Booster Set with Dedicated Sprinkler Riser

This project was a Category 2 system which included sprinkler cover to 58 flats, only those with open-plan layouts. The flats with entrance hall separating bedrooms from living/kitchens areas managed to negate the need for sprinkler protection by the fire risk strategy. We also extended protection into the duplex gym over Ground &...


The Cosmopolitan, Commercial Road, Poole

The Cosmopolitan, Commercial Road, Poole
